RADAR Monitoring Tool

Help EMC Test in detecting the Ghost Objects during the RADAR Electromagnetic Tests

What it Does?

• The Tool visualizes the ‘ghost reflections’ of the radar Sensor.

  • Electromagnetic Interference Tests of RADAR involve verification of RADAR behavior in EM conditions.

  • This involves verification of RADAR Ethernet output to check if there are any Ghost Object detections.

  • CAPL Script to analyze & identify the Ghost reflections (Side Ghost/Front Rear Ghost)

  • Python Script to visualize the reflections on a 2D reference plane

  • Technologies Used: CAPL Scripting, Python

Output

• The Tool developed to perform EMC Testing across 3 Projects.

Goosebumps.

Ghost Objects here refers to the detections 'as seen by radar' due to the interference even though there is no object.

They are not the 'Ghosts' of any Horror movie :)
